2.4 بوصة 240x320 وحدة IPS TFT Transferive

VXT240FBQS-01 هي واحدة من وحدة IPS TFT المستديرة في المصنع الصيني في Victronix. Victronix هي مورد وتجار الجملة من 2.4 بوصة 240 × 320 وحدة IPS TFT TFT مع الجودة التنافسية والسعر في الصين.

نموذج:VXT240FBQS-01

إرسال استفسار PDF تحميل

وصف المنتج

This VXT240FBQS-01 applies to 2.4 inch 240x320 Transflective IPS TFT Module panel,100nits brightness,8/16bits MCU interface, is designed for E-bike, digital camera application, industrial equipment device and other electronic products which require high quality flat panel displays, excellent visual effect, especially in strong sunlight environment.

General Specification

Item	Contents	Unit
LCD TYPE	TFT/TRANS-REFLECTIVE
MODULE SIZE (WHT)	42.7260.402.87	MM
ACTIVE SIZE(W*H)	36.72*48.96	MM
PIXEL PITCH(W*H)	0.153*0.153	MM
NUMBER OF DOTS	240*320
DRIVER IC	ST7789T3
INTERFACE TYPE	8/16-BIT MCU
TOP POLARIZER TYPE	ANTI-GLARE
RECOMMEND VIEWING DIRECTION	ALL	O'CLOCK
GRAY SCALE INVERSION DIRECTION	-	O'CLOCK
BACKLIGHT TYPE	4-DIES WHITE LED
TOUCH PANEL TYPE	-
